General Tools and Instruments GTi10-20-30-50 User Manual

Page 81

Recording File(*SAR;*SAZ)

: List SAR or SAZ files. The type is available in USB, NET, and ALL

versions.

General IR File(*JPG;*BMP)

: List JPG or BMP files with or without temperature data.

Template File(*IRW ;*IRT;*IRWX; *IRTX)

: List Analysis Working Template (IRW/IRWX) or

Report Template (IRT/IRTX) files. The type is available in PRO,

USB, NET, and ALL versions;

Optical File(*CCD;*JPG;*BMP)

: List optical image files or JPG and BMP with or without

temperature data files.

IR File(*SAT;*SAR;*JPG;*BMP)

: List all IR files with temperature data, including JPG and BMP

without temperature data files. The type is available in USB,
NET, and ALL versions.

4.1.3. Open Settings

For the PROversion, user can set open criteria that include Temp Screening, Temp Label, Tool
Template, Image Adjusting, and/or Palette. The Open Settings will be saved when you exit the
application.
（1）

select menu File => Open => click the blue triangle;

（2）In analysis or report mode, click the setting shortcut
