Shooting, Freezing / activating an image – General Tools and Instruments GTi10-20-30-50 User Manual
Page 31
31
Shooting
Making Camera Adjustments
Freezing / Activating an Image
You can activate/freeze a thermal image by configuring the trigger
to do so.
1
Make sure that the thermal camera is in null mode (see
p. 14).
Press the MENU/ENTER button to open the Main
Menu.
2
Press the UP or DOWN arrow to
navigate to the Trigger Setup line.
Then press the MENU/ENTER button
to open the Trigger Setup menu.
• Use the LEFT and RIGHT arrows
to select Freeze/Live among the
three options for the trigger. (The
other two options are Torch On
and Save File.) To set up the
trigger for Torch Off, press the
MENU/ENTER button while the
display shows Torch On.
3
After this operation, press the MENU/ENTER button to
save the selection, or press the ESC button to return to
the System Setup menu without saving.
