AFC1500 Multi-2 Unit Hardware Manual (Rev2.1)
PAGE 5 - 47
Chapter 5: Control Interfaces
5.9.3 Input Signals
Inputs are assigned in the order as shown in the table below and cannot be changed. Bits
designated as “Unused” have no input assigned to them.
Note: For signal definitions see Section 4.7.2
Address Signal
FEC Multi-2
Bank Bit
RY(n+0)0 Emergency Stop 1
RY(n+0)1 Reset 2
RY(n+0)2 Reverse 3
RY(n+0)3 Start 4
RY(n+0)4 Sequence Select 0 5
RY(n+0)5 Sequence Select 1 6
RY(n+0)6 Sequence Select 2 7
RY(n+0)7 Sequence Select 3 8
RY(n+0)8 Cycle Count Up 9
RY(n+0)9 Cycle Count Clear 10
RY(n+0)A Self Check Disable 11
RY(n+0)B Unused 12
RY(n+0)C INPORT 1 13
RY(n+0)D INPORT 2 14
RY(n+0)E INPORT 3 15
RY(n+0)F INPORT 4 16
Address Signal
FEC Multi-2
Bank Bit
RY(n+1)0 BYPASS SP#1 17
RY(n+1)1 BYPASS SP#2 18
RY(n+1)2 BYPASS SP#3 19
RY(n+1)3 BYPASS SP#4 20
RY(n+1)4 BYPASS SP#5 21
RY(n+1)5 BYPASS SP#6 22
RY(n+1)6 BYPASS SP#7 23
RY(n+1)7 BYPASS SP#8 24
RY(n+1)8 BYPASS SP#9 25
RY(n+1)9 BYPASS SP#10 26
RY(n+1)A Unused 27
RY(n+1)B Unused 28
RY(n+1)C Unused 29
RY(n+1)D Unused 30
RY(n+1)E Unused 31
RY(n+1)F Unused 32
Address Signal
FEC Multi-2
Bank Bit
RY(n+2)0 BYPASS SP#11 33
RY(n+2)1 BYPASS SP#12 34
RY(n+2)2 BYPASS SP#13 35
RY(n+2)3 BYPASS SP#14 36
RY(n+2)4 BYPASS SP#15 37
RY(n+2)5 BYPASS SP#16 38
RY(n+2)6 BYPASS SP#17 39
RY(n+2)7 BYPASS SP#18 40
RY(n+2)8 BYPASS SP#19 41
RY(n+2)9 BYPASS SP#20 42
RY(n+2)A BYPASS SP#21 43
RY(n+2)B BYPASS SP#22 44
RY(n+2)C BYPASS SP#23 45
RY(n+2)D BYPASS SP#24 46
RY(n+2)E BYPASS SP#25 47
RY(n+2)F BYPASS SP#26 48
Address Signal
FEC Multi-2
Bank Bit
RY(n+3)0 BYPASS SP#27 49
RY(n+3)1 BYPASS SP#28 50
RY(n+3)2 BYPASS SP#29 51
RY(n+3)3 BYPASS SP#30 52
RY(n+3)4 BYPASS SP#31 53
RY(n+3)5 54
RY(n+3)6 55
RY(n+3)7 56
RY(n+3)8 57
RY(n+3)9 58
RY(n+3)A 59
RY(n+3)B 60
RY(n+3)C 61
RY(n+3)D 62
RY(n+3)E 63
RY(n+3)F 64
