AFC1500 Multi-2 Unit Hardware Manual (Rev2.1)
PAGE 5 - 78
Chapter 5: Control Interfaces
Output Signals (Toolsnet Version)
The Output signal layout for first 7 bytes ( 0 – 55 bits ) can be changed by
programming the PLC output layout. (AFC User Console Software)
Byte 7 (56bit – 63bit) are fixed output. (Required by Toolsnet)
Byte No. Bit Signal Byte No. Bit Description
Byte 0
0bit Total Reject
Byte 2
16bit Spindle #1 Accept
1bit Total Accept 17bit Spindle #2 Accept
2bit N/R Abnormal 18bit Spindle #3 Accept
3bit Ready 19bit Spindle #4 Accept
4bit Busy 20bit Spindle #5 Accept
5bit End 21bit Spindle #6 Accept
6bit 22bit Spindle #7 Accept
7bit 23bit Spindle #8 Accept
Byte 1
8bit Sequence Select 0
Byte 3
24bit Spindle #9 Accept
9bit Sequence Select 1 25bit Spindle #10 Accept
10bit Sequence Select 2 26bit Spindle #11 Accept
11bit Sequence Select 3 27bit Spindle #12 Accept
12bit Output Port 1 28bit Spindle #13 Accept
13bit Output Port 2 29bit Spindle #14 Accept
14bit Output Port 3 30bit Spindle #15 Accept
15bit Output Port 4 31bit Spindle #16 Accept
Byte No. Bit Signal Byte No. Bit Description
Byte 4
32bit Spindle #18 Accept
Byte 6
48bit As programmed
33bit Spindle #19 Accept 49bit As programmed
34bit Spindle #20 Accept 50bit As programmed
35bit Spindle #21 Accept 51bit As programmed
36bit Spindle #22 Accept 52bit As programmed
37bit Spindle #23 Accept 53bit As programmed
38bit Spindle #24 Accept 54bit As programmed
39bit Spindle #25 Accept 55bit As programmed
Byte 5
40bit Spindle #26 Accept
Byte 7
56bit Network Connected
41bit Spindle #27 Accept 57bit Data Buffer Full
42bit Spindle #28 Accept 58bit
43bit Spindle #29 Accept 59bit
44bit Spindle #30 Accept 60bit
45bit Spindle #31 Accept 61bit
46bit As programmed 62bit
47bit As programmed 63bit
