AFC1500 Multi-2 Unit Hardware Manual (Rev2.1)
PAGE 5 - 83
Chapter 5: Control Interfaces
Output Signals (Toolsnet Version-Continued)
Example output:
Torque value 260.5 Nm
Angle value 515.9 Degree
Byte No. Bit Signal Byte No. Bit Description
Byte 8
64bit Off
Byte 10
80bit Off
65bit Off 81bit Off
66bit Off 82bit Off
67bit Off 83bit Off
68bit Off 83bit Off
69bit Off 85bit Off
70bit Off 86bit Off
71bit On 87bit Off
Byte 9
72bit Off
Byte 11
88bit Off
73bit Off 89bit Off
74bit Off 90bit Off
75bit Off 91bit Off
76bit Off 92bit Off
77bit On 93bit On
78bit Off 94bit Off
79bit Off 95bit On
Byte No. Bit Signal Byte No. Bit Description
Byte 12
96bit Off
Byte 14
112bit Off
97bit Off 113bit Off
98bit Off 114bit Off
99bit Off 115bit Off
100bit Off 116bit Off
101bit Off 117bit Off
102bit On 118bit Off
103bit Off 119bit Off
Byte 13
104bit Off
Byte 15
120bit Off
105bit Off 121bit Off
106bit Off 122bit Off
107bit Off 123bit Off
108bit Off 124bit On
109bit Off 125bit Off
110bit On 126bit Off
111bit On 127bit On
260 Decimal 5 Decimal
515 Decimal
Byte 8/9 value left
of decimal
Byte 10/11 value
right of decimal
9 Decimal
Byte 12/13 value
left of decimal
Byte 14/15 value
right of decimal
