MOD 30ML Operation
APPENDIX A - EVENT CODES
A-20
Table A-2. Event Codes, Description and Action
Block
Type Codes
Full Message Text
Description/Action
WDOM
4
BLOCK MODE SET TO AUTO
Information only.
WDOM
5
BLOCK MODE SET TO MANUAL
Information only.
WDOM
6
I/O MISMATCH
A slot configured for a digital module contains
an intelligent module (analog input, analog
output, ICN, MSC or RIO).
NOTE: This diagnostic cannot distinguish
between an empty slot and a digital I/O module
or between different types of digital modules.
WDOM
7
WDO_MODULE_ERROR
One of the following conditions was detected:
• The module readback value is not the same
as the previous result value.
• The select circuit, which is used to
communicate with the module blocks, has a
diagnostic error. In this case, all modules
report this diagnostic.
WRIM
4
BLOCK MODE SET TO AUTO
Information only.
WRIM
5
BLOCK MODE SET TO MANUAL
Information only.
WRIM
6
I/O MISMATCH
A configured slot is either empty or the installed
module does not match the slot configuration.
WRIM
7
I/O COMMUNICATIONS ERROR
One of the following conditions was detected:
• There is a checksum error in the
communications between this block and the
module.
• The select circuit, which is used to
communicate with the module, has a
diagnostic error. In this case, all modules
report a communications error.
WRIM
8
WRIM MODULE ERROR
The module has reported an error which is
identified by an extended error code. The
error codes can be viewed via Attribute No.18,
Extended Error (EXTERR).
