MOD 30ML Operation
SETUP
2-13
Table 7. System Template Configuration (Cont’d)
Step Step Description Line 1 Line 2 Line 6 Entry Description
7D10 Low Priority Process Alarm Beep
∇ ∆ change value, ENT enters
NXT, PRV change step
LOW PRI BEEP OFF OFF = beeping is disabled
ENABLE = beep on alarm
7D11 System (Alarms Exit)
∆ moves up to Step 7D
NXT, PRV change step
SYSTEM
7E System (System List Exit)
∆ moves up to Step 6B1
NXT, PRV change step
SYSTEM
Table 8. User Compound Template Configuration
Step Step Description Line 1 Line 2 Line 6 Entry Description
8A Tag ID String
∇ ∆ changes a character
NXT, PRV flash to change position
ENT enters new device tag.
NXT, PRV change step
TAG ID STRING CTAG01 Modify compound tag using
standard set of characters. This 8
character
ascii string identifies
compound (e.g. TIC-101).
8B Compound Type
∇ ∆ changes type
ENT requires verification (8B1).
NXT, PRV change step
CTAG01 CMP TYPE SNGLLOOP Enter the type of compound to be
built: SNGLLOOP = Single loop or
MASTER C = Master compound.
MASTER C includes a SLAVE C
(the output of the master drives the
setpoint of the slave).
8B1 Change Compound Type?
∇ ∆ changes value (a change from
YES to NO returns you to Step 8B)
ENT accepts YES
PRV returns to step 8A
CHANGE TYPE? NO Verify change. If one single loop
compound exists, the one you are
in (CTAG01) will change to the
Master and another (CTAG02) will
be added as a Slave. Changing
from Master to single loop causes
both the master and slave
compounds to become single loop.
8C Scan Group
∇ ∆ changes group, ENT enters.
NXT, PRV change step
CTAG01 SCAN GRP 1 Enter a scan group (Task) number
(1 to 5) in which this compound is
to be executed.
8D Process Input (Entry)
∇ moves down to Step 8D1
NXT, PRV change step
CTAG01 PROC INP
8D1 Process Input Slot (location)
∇ ∆ changes slot, ENT enters
NXT, PRV change step
PROC INP SLOT BI AIN 1 Identify process input as NONE,
BI AIN 1, BI AIN 2 or module slot
S01- to S11- for input being
configured (use higher slot number
for double wide modules).
8D2 Process Input Type
∇ ∆ changes type, ENT enters
NXT, PRV change step
PROC INP INP TYPE VOLTS Select type as: VOLTS, MVOLTS,
CURRENT, RESIST, THRMOCPL
1 Slot: RTD2WIRE, CURRNT2W
2 Slots: RTD3WIRE, WIDERES
Built-in only: TC W/CJC, RTD
8D3 Process Input Filter
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP FILTER 0.00 0 = no filtering (last sampled value
is the input value). Value = time in
minutes up to 100. Large filter
values tend to maintain the
previous input value.
