MOD 30ML Operation
SETUP
2-15
Table 8. User Compound Template Configuration (Cont’d)
Step Step Description Line 1 Line 2 Line 6 Entry Description
RTD Inputs Only:
8D4
(RTD) Process Input RTD Type
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP RTD TYPE PT3850 PT3850
PT3923
PT3902
PT3911
NI6270
8D5
(RTD) Process Input Temperature Scale
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP TEMPSCAL CELSIUS Celsius
Kelvin
Rankine
Farenheit
8D6
(RTD) Process Input Resistance Range
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP RES RNGE LOW LOW (built-in = 0 to 55 ohms)
NORMAL (built-in = 0 to 430 ohms)
8D7
(RTD) Process Input Nominal Resistance
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP NOM RES 0.00 Resistance produced by RTD in
ohms at zero degrees Celsius.
Ranges are: 2-Wire module (0 to
4000), 3-Wire module (0 to 400),
BI AIN (0 to 430).
8D8
(RTD) Process Input Leadwire Resistance
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP LW RES 0.00 Leadwire resistance in ohms.
Values that cause the sum of the
leadwire resistance and the input to
exceed maximum resistance will
cause an overrange error.
8D9
(RTD) Process Input Zero
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP ZERO 0.00 Specify zero calibration value in
result units.
8D10
(RTD) Process Input Span
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP SPAN 1.00 One is nominal. Specify span
calibration value in result units.
All Inputs:
8D11 Process Input Display Format
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP DISP FMT FLOAT 3 Float 0 = x
Float 1 = x.x
Float 2 = x.xx and so forth to
Float 6 = x.xxxxxx
8D12 Process Input Low Engineering Unit
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP LO ENGU 0.000 0% value in engineering units.
8D13 Process Input High Engineering Unit
∇ ∆ change value, ENT enters
NXT, PRV change step
PROC INP HI ENGU 100.000 100% value in engineering units.
8D14 Process Input Engineering Unit
Label (not for TC or RTD)
∇ ∆ changes a character
NXT, PRV flash to change position
ENT enters new label.
NXT, PRV change step
PROC INP EU LABEL Up to a 4 character label to appear
after process input value. Value
has precedence over label. First
character entered becomes
leftmost character.
