MOD 30ML Operation
INTRODUCTION
1-4
1.4
VERSION IDENTIFICATION
To verify the version level of the instrument, check the version number marked on the PROM
label of the identity module. The firmware version is a digit in the catalog number as follows:
Catalog Number Description for 2004P
MOD 30ML PANEL-MOUNT
06
07-08
09
10
11
12
13 14 15
Base Controller
Standard bezel
Narrow bezel (Foxboro replacement version)
1800RZ
1801RZ
Approvals
General Purpose
CE (European Community destinations only)
FM/CSA Class 1 Division 2 A,B,C,D
10
12
21
Power Supply
24V dc
85 to 265V ac
0
1
Enclosure
Standard terminations
Standard terminations, NEMA 4
Standard terminations, NEMA 4 with conformal
coating
0
3
4
Not Used
0
Design Model
General Purpose, FM/CSA approval
European Approval (CE Certification - for
European Community destinations)
A
B
Programming / Special Features
None
S T D
Sample Number
1800PZ10102C (Product is serialized)
Version number identification is also available in the *DEVICE* ABOUT displays as
described in setup Table 5.
