MOD 30ML Operation
SETUP
2-5
Table 1. Device Status (Cont’d)
Step Step Description Line 1 Line 2 Line 6 Entry Description
1C4
Reset Command
∇ ∆ select YES/NO, ENT enters.
NXT, PRV change step
COMMANDS RESET NO Use to complete tasks and then
perform a power-up.
Press ENT after selecting YES.
1C5
Kill Command
∇ ∆ select YES/NO, ENT enters.
NXT, PRV change step
COMMANDS KILL NO Use to perform an immediated
power-up.
Press ENT after selecting YES.
1C6
Delete Main Database Command
∇ ∆ select YES/NO, ENT enters.
NXT, PRV change step
COMMANDS DEL MAIN NO Use to mark the main database as
bad and set the instrument state to
DEFAULT.
Press ENT after selecting YES.
1C7
Restore Main Database Command
∇ ∆ select YES/NO, ENT enters.
NXT, PRV change step
COMMANDS RES MAIN NO Use to mark the main database as
good (in case delete was issued by
mistake) and if verified as good will
attempt to set the instrument state
to RUN.
Press ENT after selecting YES.
1C8 Device Status Commands (Exit)
∆ moves up to Step 1C
COMMANDS DEV STAT
1D Device Execution Times (Entry)
∇ moves down to Step 1D1
DEV STAT XTIMES Scan groups 1 through 5 are user
defined intervals for loops. The
fastest group has the highest
priority. The lower numbered group
has a higher priority if the interval is
the same.
Scan group 6 is a system group
Scan groups 7 to 9 are
communications groups.
1D1
Scan 1 Execution Time
NXT, PRV change step
XTIMES T1 IMMED 0:00.000 Recent millisecond scan time for
the associated scan group.
1D2 Scan 2 Execution Time XTIMES T2 IMMED 0:00.000 “
1D3 Scan 3 Execution Time XTIMES T3 IMMED 0:00.000 “
1D4 Scan 4 Execution Time XTIMES T4 IMMED 0:00.000 “
1D5 Scan 5 Execution Time XTIMES T5 IMMED 0:00.000 “
1D6 Scan 6 Execution Time XTIMES T6 IMMED 0:00.000 “
1D7 Scan 7 Execution Time XTIMES T7 IMMED 0:00.000 “
1D8 Scan 8 Execution Time XTIMES T8 IMMED 0:00.000 “
1D9 Scan 9 Execution Time XTIMES T9 IMMED 0:00.000 “
1D10
Scan 1 Filtered Execution Time XTIMES T1 FILTD 0:00.000 Average millisecond scan time for
the associated scan group
(updates after group executes).
1D11 Scan 2 Filtered Execution Time XTIMES T2 FILTD 0:00.000 “
1D12 Scan 3 Filtered Execution Time XTIMES T3 FILTD 0:00.000 “
1D13 Scan 4 Filtered Execution Time XTIMES T4 FILTD 0:00.000 “
1D14 Scan 5 Filtered Execution Time XTIMES T5 FILTD 0:00.000 “
1D15 Scan 6 Filtered Execution Time XTIMES T6 FILTD 0:00.000 “
1D16 Scan 7 Filtered Execution Time XTIMES T7 FILTD 0:00.000 “
1D17 Scan 8 Filtered Execution Time XTIMES T8 FILTD 0:00.000 “
1D18 Scan 9 Filtered Execution Time XTIMES T9 FILTD 0:00.000 “
