MOD 30ML Operation
SETUP
2-11
Table 6. Template Configuration (Cont’d)
Step Step Description Line 1 Line 2 Line 6 Entry Description
6C Install Template
∇ move down to 6C1
NXT, PRV change step
INSTALL TEMPLATE Installation verifies and loads the
template making it the active
database (changes state to RUN).
6C1 Installation of Template
∇ ∆ select YES (press again from
NONE returns you to Step 6C)
ENT loads template and displays
first runtime display.
INSTALL TYPE NONE Select NONE to exit installation.
Select INITCOLD to install and
RUN template using a cold start.
Select INITWARM to install and
RUN template using a warm start.
6C2 Configuration Request Failed
ACK acknowledges failure
message and changes to Step 6B.
CONFIG REQUEST FAILED Data base verification failed
because of some inconsistency in
database or an active shutdown
condition. To ACK failure, go to
DEV STAT level and set ACK SD
to Yes (Step 1B5).
6D Template (Exit)
∆ moves up to Step 6
NXT, PRV change step
TEMPLATE
Table 7. System Template Configuration
Step Step Description Line 1 Line 2 Line 6 Entry Description
7A System Device Tag
∇ ∆ change a character
NXT, PRV flash to change position
ENT enters new device tag.
NXT, PRV change step
SYSTEM DEV TAG TEMP 100 Modify device tag using standard
set of characters. This tag identifies
instrument.
7B System Scan Groups (Entry)
∇ moves down to Step 7B1
NXT, PRV change step
SYSTEM SCANGRPS Scan groups 1 through 5 are user
defined intervals for loops. The
fastest group has the highest
priority. The lower numbered group
has a higher priority if the interval is
the same.
7B1 Scan Group 1 Interval
∇ ∆ changes interval, ENT enters
NXT, PRV change step
SCAN GROUP 1 0:00.100 Set group scan interval.
(50ms to 50:00.000 Hrs)
7B2 Scan Group 2 Interval
∇ ∆ changes interval, ENT enters
NXT, PRV change step
SCAN GROUP 2 0:00.000 Set group scan interval.
(0 to 50:00.000 Hrs)
7B3 Scan Group 3 Interval
∇ ∆ changes interval, ENT enters
NXT, PRV change step
SCAN GROUP 3 0:00.000 Set group scan interval.
(0 to 50:00.000 Hrs)
7B4 Scan Group 4 Interval
∇ ∆ changes interval, ENT enters
NXT, PRV change step
SCAN GROUP 4 0:00.000 Set group scan interval.
(0 to 50:00.000 Hrs)
7B5 Scan Group 5 Interval
∇ ∆ changes interval, ENT enters
NXT, PRV change step
SCAN GROUP 5 0:00.000 Set group scan interval.
(0 to 50:00.000 Hrs)
7B6 System (Tasks Exit)
∆ moves up to Step 7B
NXT, PRV change step
SYSTEM
