MOD 30ML Operation
SETUP
2-10
2.5 TEMPLATE SETUP
The general procedure for working with a new template configuration is to load defaults, edit
system parameters, edit first user compound, insert any new user compounds and then edit
them. After configuring compounds for single loop PID or Master Slave Cascade control, you
then install the database.
* NOTE INSERT places a new compound in the list AFTER the current compound.
DELETE deletes the current compound. The System compound cannot be
deleted.
Table 6. Template Configuration
Step Step Description Line 1 Line 2 Line 6 Entry Description
6 Device Templates
∇ moves down to Step 6A if
defaults are not loaded otherwise
move down to Step 6B.
NXT goes to Step 1 (Status)
PRV goes to Step 5 (About)
*DEVICE* NOT CFGD
or
DEV TAG
TEMPLATE These steps are protected by the
CONFIG password. Enter proper
password, if used, to move down.
If the message MAIN DB HAS NO
TEMPLATE appears, a database
loaded by the Application Builder is
present. This main database must
be deleted to access templates.
6A Load Template Defaults
∇ moves down to Step 6A1
NXT, PRV change step
LOAD DEFAULTS Use the default template as a
starting point for creation of a data
base. Default values are the basis
for what is shown here.
6A1
Verify Loading Defaults
∇ ∆ select YES (press again ret-
urns you to Step 1 - Changes inst-
rument state & sends you back)
ENT loads defaults from YES and
changes to Step 6B..
VERIFY LOAD Defaults provide a System
Compound (Table 7 list defaults in
the line 6 column) and the CTAG01
Compound (Table 8 list defaults in
the line 6 column).
6B Edit Template
∇ moves down to Step 6B1
NXT, PRV change step
EDIT TEMPLATE
6B1 System Compound List
∇ ∆ select List, Insert, Edit
ENT to insert (same as step 6B2)
or edit (Step 7A, Table 7).
NXT, PRV change step
CMP LIST *SYSTEM* LIST Select LIST to stay at current
compound list level.
Select INSERT to add a user
compound after system compound.
Select EDIT to access the system
compound.
6B2 First User Compound List
∇ ∆ select List, Delete, Insert, Edit
ENT to insert or edit (Step 8A,
Table 8) or delete (Step 6B21).
NXT, PRV change step
CMP LIST CTAG01 LIST Select LIST to access current user
compounds.
Select DELETE to remove the
current user compound.
Select INSERT to add a user com-
pound after current compound.
Select EDIT to access the current
compound.
6B21 Verify Delete?
∇ ∆ select YES, NO
ENT from NO (Step 6B2) or from
YES to delete (Step 6B3).
NXT, PRV change step
VERIFY DELETE? NO No = do not delete
Yes = delete compound
6B3 Compound List
∆ moves up to Step 6B
NXT, PRV change step
CMP LIST
