MOD 30ML Operation

SETUP

2-8

Table 3. Device I/O Status

Step

Step Description

Line 1

Line 2

Line 6

Entry Description

Device I/O

∇ moves down to Step 3A

NXT goes to Step 4 (Events)

PRV goes to Step 2 (Setup)

*DEVICE* NOT CFGD

or
DEV TAG

I/O

These steps are protected by the
CONFIG password. Enter proper
password, if used, to move down.

Built in Analog Input 1

AUT, MAN change mode

NXT, PRV change step

BI AIN 1 UNCONFIG

or LABEL

& VALUE

Unconfigured or ‘module’ type and
value shown. Press manual key to
change line 3 to (MAN) and get

∇ ∆

keys. Change value from here.
Leave in auto (AUT) to get field
result.

Built in Analog Input 2

Same as Input 1

BI AIN 2 UNCONFIG

or LABEL

& VALUE

“

Built in Analog Output 1

Same as Input 1

BI AOUT1 UNCONFIG

or LABEL

& VALUE

“

Built in Analog Output 2

Same as Input 1

BI AOUT1 UNCONFIG

or LABEL

& VALUE

“

Module Position 1

Same as Input 1

S01 UNCONFIG

or LABEL

& VALUE

“

Module Position 2

Same as Input 1

S02 UNCONFIG

or LABEL

& VALUE

“

Module Position 3

Same as Input 1

S03 UNCONFIG

or LABEL

& VALUE

“

Module Position 4

Same as Input 1

S04 UNCONFIG

or LABEL

& VALUE

“

Module Position 5

Same as Input 1

S05 UNCONFIG

or LABEL

& VALUE

“

Module Position 6

Same as Input 1

S06 UNCONFIG

or LABEL

& VALUE

“

Module Position 7

Same as Input 1

S07 UNCONFIG

or LABEL

& VALUE

“

Module Position 8

Same as Input 1

S08 UNCONFIG

or LABEL

& VALUE

“

Module Position 9

Same as Input 1

S09 UNCONFIG

or LABEL

& VALUE

“

Module Position 10

Same as Input 1

S10 UNCONFIG

or LABEL

& VALUE

“

Module Position 11

Same as Input 1

S11 UNCONFIG

or LABEL

& VALUE

“

Device I/O (Exit)

∆ moves up to Step 3

NXT, PRV change step

I/O *DEVICE*
