Table 8. User Compound Template Configuration (Cont’d)
Step Step Description Line 1 Line 2 Line 6 Entry Description
8F Control Type (Entry)
∇ moves down to Step 8F1
NXT, PRV go to 8F, 8D
CTAG01 CONTROL
8F1
Control Algorithm Type
∇ ∆ change value, ENT enters
NXT, PRV change step
Values are: ESPO, PMPO, EMPO,
EOEO, ESEO, EMEO, EOOE, EOPE,
EOEE, EOOO, OSOO, PSOO, ESOO,
OMOO, PMOO, EMOO, EOPO, PSPO
CONTROL ALGO TYP ESPO Gain (1st Character):
O
= Off
P = On Process
E = On Error
Reset (2nd Character):
O
= Off
S = Standard
M = Micro-Scan
Pre-Act (3rd Character):
O
= Off
P = On Process
E = On Error
Manual Reset (4th Character):
O
= Off
E = Enabled
8F2
Control Action
∇ ∆ change value, ENT enters
NXT, PRV change step
CONTROL ACTION REVERSE Reverse (output decreases as
process rises above setpoint),
Direct (output increases as process
rises above setpoint)
8F3
Gain
∇ ∆ change value, ENT enters
NXT, PRV change step
GAIN 0.01 0.01 to 125.0
Proportional response in a fixed
gain controller.
8F4
Reset
∇ ∆ change value, ENT enters
NXT, PRV change step
RESET 0.01 0.01 to 125.0
Reset in repeats per minute.
8F5
Preact
∇ ∆ change value, ENT enters
NXT, PRV change step
PREACT 0.00 0.00 = Off
0.07 to 32 preact time base value.
8F6
Control Input Filter Type
∇ ∆ change value, ENT enters
NXT, PRV change step
CONTROL FILTYPE NONE NONE = No low pass filter (last
sampled value is input value)
PRE AUTO = Preact Auto type low
pass filter based on derivative time
and task execution rate.
PRE USER = Filter time applied to
derivative (on process error) signal
before use in PID.
PROCUSER = Filter time applied
to process (on process error) signal
before use in PID.
8F7
Filter Value
∇ ∆ change value, ENT enters
NXT, PRV change step
FILTER 0.00 Filter Time in minutes. Small
values maintain recent input and
large values maintain previous
input.
8F8
Control Manual Reset Balance Type
∇ ∆ change value, ENT enters
NXT, PRV change step
CONTROL MR TYPE NONE NONE = No manual reset balance.
PRCDLESS = Procedureless
manual reset (value recalculated
on a transfer to auto). Calculation
compares output and error signals
(MR = output - (gain * error).
