MOD 30ML Operation
SETUP
2-6
Table 1. Device Status (Cont’d)
Step Step Description Line 1 Line 2 Line 6 Entry Description
1D10
Scan 1 Maximum Execution Time XTIMES T1 MAX 0:00.000 Maximum millisecond scan time for
the associated scan group since
entering the current instrument
state.
1D11 Scan 2 Maximum Execution Time XTIMES T2 MAX 0:00.000 “
1D12 Scan 3 Maximum Execution Time XTIMES T3 MAX 0:00.000 “
1D13 Scan 4 Maximum Execution Time XTIMES T4 MAX 0:00.000 “
1D14 Scan 5 Maximum Execution Time XTIMES T5 MAX 0:00.000 “
1D15 Scan 6 Maximum Execution Time XTIMES T6 MAX 0:00.000 “
1D16 Scan 7 Maximum Execution Time XTIMES T7 MAX 0:00.000 “
1D17 Scan 8 Maximum Execution Time XTIMES T8 MAX 0:00.000 “
1D18 Scan 9 Maximum Execution Time XTIMES T9 MAX 0:00.000 “
1D19
Base Scan Time XTIMES BASE SCN 0:00.050 Average millisecond of processor
time between base scan ticks.
00:00:00.050, unless
overconfigured.
1D20
Scan Idle Time XTIMES IDLE TM 0:00.039 Average millisecond of unused
processor time between base scan
ticks.
1D21 Device Status Xtimes (Exit)
∆ moves up to Step 1D
XTIMES DEV STAT
1E
Device Status Time
∇ ∆ changes a number
NXT, PRV flash to change position
ENT enters.
NXT, PRV change step
DEV STAT TIME HH:MM:SS Current time. The instrument
maintains this time even when off.
Always keep set to current time.
1F
Device Status Date
∇ ∆ changes a number
NXT, PRV flash to change position
ENT enters.
NXT, PRV change step
DEV STAT DATE DD:MM:YY Current date. The instrument
maintains this date even when off.
Always keep set to current date.
1G
Device Status Day
∇ ∆ changes day ENT enters.
NXT, PRV change step
DEV STAT DAY 3 Current day (Sunday = 1, Saturday
= 7). The instrument maintains this
day even when off. Always keep
set to current day.
1H Device Status (Exit)
∆ moves up to Step 1
DEV STAT *DEVICE*
Table 2. Device Setup
Step Step Description Line 1 Line 2 Line 6 Entry Description
2 Device Setup
∇ moves down to Step 2A
NXT goes to Step 3 (I/O)
PRV goes to Step 1 (Status)
*DEVICE* NOT CFGD
or
DEV TAG
SETUP See Table 3 for step 3 (I/O)
See Table 1 for step 1 (Status)
