MOD 30ML Operation
APPENDIX A - EVENT CODES
A-9
Table A-2. Event Codes, Description and Action (Cont’d)
Block
Type Codes
Full Message Text Description/Action
IF 44 I/O OVERRUN The instrument is unable to complete all I/O
sampling at the intervals specified. The scan
execution times should be examined to
determine which tasks should be simplified or
run at a slower rate. Note that when the
instrument is overconfigured, all tasks will run
at a proportionally slower rate.
IF 45 COMM HARDWARE FAULT A communication module is installed in slots 9
and 10 of a MOD 30ML (1800R) and the built-in
communication jumpers are set for built-in
communication; a conflict of resources occurs
since both require use of communication port 1.
The instrument is placed in the DEFAULT state.
No block is built for either case, leaving PC
communication only available via a
communication module in slot 7 & 8.
IF 46 EEPROM FAULT The data stored in EEPROM of a MOD 30ML
(1800R) could not be loaded into the instrument
database. Default values were loaded and are
being used. The data values include the
calibration data for the built-in I/O and
communication parameters for built-in
communication port.
IF 47 MEMORY MODULE DOWNLOAD FAILED The memory module database was not
downloaded. Another diagnostic will be present
to indicate why the download did not happen.
IF 128 DOWNLOAD FROM MEMORY MODULE Information only: The memory module
database was downloaded to main RAM.
IF
129 UPLOAD TO MEMORY MODULE Information only: The user database was
uploaded to the memory module.
IF
130 DOWNLOAD FROM SYSTEM Information only: A full or partial database
download was received from the external
system.
IF
131 UPLOAD TO SYSTEM Information only: A database was uploaded to
the external system.
IF
132 INSTRUMENT IN UPLOAD STATE Information only: The instrument has entered
the upload state and is now running the default
database.
IF
133 INSTRUMENT IN DEFAULT STATE Information only: The instrument has entered
the default state and is now running the default
database.
IF
134 INSTRUMENT BEING CONFIGURED Information only: The instrument has entered
the being configured state and is running the
default database to make the main database
area available for downloading.
