MOD 30ML Operation
APPENDIX A - EVENT CODES
A-14
Table A-2. Event Codes, Description and Action
Block
Type Codes
Full Message Text
Description/Action
RDOM
4
CHANNEL 0 MODE SET TO AUTO
Information only.
RDOM
5
CHANNEL 0 MODE SET TO MANUAL
Information only.
RDOM 6
•••
Repeat for Channels 1 to 14
RDOM
34
CHANNEL 15 MODE SET TO AUTO
Information only.
RDOM
35
CHANNEL 15 MODE SET TO MANUAL
Information only.
RDOM
36
I/O MISMATCH
A configured address on the CS-31 bus is not
used or the installed remote module does not
match the address configuration.
RDOM
37
MODULE EXTENDED ERROR
A remote module has reported an error.
Codes identifying reported errors are stored in
the block database as extended errors. The
error codes can be viewed via Attribute Nos. 15
- 30, Extended Error (EXTERR).
RI
0
BLOCK STATE SET TO RUN
Information only.
RI
1
BLOCK STATE SET TO HOLD
Information only.
RI
2
BLOCK STATE SET TO OFF
Information only.
RI
3
BLOCK STATE SET TO DEBUG
Information only.
RI
4
CALCULATION ERROR
A calculation error (calculation overflow or
divide by zero) has been detected. The block
completes the calculation using some
reasonable value (+ or - maximum value for
overflows and divide by zero), and sets the
output quality bad if Attribute No. 10, Set quality
bad on calculation error? (SETQBAD) is YES.
The diagnostic error clears and the quality is
set back to good when a subsequent execution
of the block performs a successful calculation.
RIM
4
BLOCK MODE SET TO AUTO
Information only.
RIM
5
BLOCK MODE SET TO MANUAL
Information only.
RIM
6
I/O MISMATCH
A configured slot is either empty or the installed
module does not match the slot configuration.
RIM
7
I/O COMMUNICATIONS ERROR
One of the following conditions was detected:
• A checksum error in the communications
between this block and the module.
• The select circuit, which is used to
communicate with the module, has a
diagnostic error. In this case, all modules
report a communications error.
RIM
8
RIM MODULE ERROR
The module has reported an error which is
identified by an extended error code. The
error codes can be viewed via Attribute No.18,
Extended Error (EXTERR).
