MOD 30ML Operation
SETUP
2-19
Table 8. User Compound Template Configuration (Cont’d)
Step Step Description Line 1 Line 2 Line 6 Entry Description
8F9
Manual Reset Value
∇ ∆ change value, ENT enters
NXT, PRV change step
MR VAL 0.00 Enter initial manual reset value
(-10.0 to 100.0 %) for proportional
only controllers.
8F10
Feed Forward Compensation Input
(Entry)
∇ moves down to Step 8F10A
NXT, PRV change step
FEED FORWARD Value to be added or multiplied to
output of PID.
8F10A Feed Forward Compensation Input
Slot Position
∇ ∆ change value, ENT enters
NXT, PRV change step
FEED FWD SLOT NONE None, BI AIN 1, BI AIN 2, S01 to
S11
8F10B Feed Forward Input Type
∇ ∆ change value, ENT enters
NXT, PRV change step
FEED FWD INP TYPE VOLTS Select type as: VOLTS, MVOLTS,
CURRENT, RESIST, THRMOCPL
1 Slot: RTD2WIRE, CURRNT2W
2 Slots: RTD3WIRE, WIDERES
Built-in only: TC W/CJC, RTD
8F10C Feed Forward Input Setup
Same as process value inputs.
See Process Value input setup.
Specify range in % of output.
8F10D Feed Forward Input Setup (Exit)
∆ moves up to Step 8F10
NXT, PRV change step
FEED FWD
8F11 Feed Forward Gain
∇ ∆ change value, ENT enters
NXT, PRV change step
FF GAIN Enter value to be multiplied against
feed forward input before the FF
CALC is applied to the PID auto
output.
8F12 Feed Forward Bias
∇ ∆ change value, ENT enters
NXT, PRV change step
FF BIAS Enter % output value to be added
to feed forward input before the FF
CALC is applied to the PID auto
output.
8F13
Feed Forward Calculation
∇ ∆ change value, ENT enters
NXT, PRV change step
FF CALC ADD ADD = FF input with gain and bias
added to PID auto output
MULTIPLY = FF input with gain
and bias multiplied against PID
auto output
8F14
Output Mode Restart Value
(not used with MASTER C)
∇ ∆ change value, ENT enters
NXT, PRV change step
RESTART MODE PREVIOUS PREVIOUS, MANUAL, AUTO
Used on cold or frozen restart.
Mode cannot conflict with allowed
modes.
8F15 Initial Mode for Previous
∇ ∆ change value, ENT enters
NXT, PRV change step
INITIAL MODE MANUAL MANUAL
AUTO
8F16 Control Type (Exit)
∆ moves up to Step 8F
NXT, PRV change step
COMPOUND
