MOD 30ML Operation
SETUP
2-21
Table 8. User Compound Template Configuration (Cont’d)
Step Step Description Line 1 Line 2 Line 6 Entry Description
8H2 Deviation Alarms DEVIATN ALARMS
8H2A Deviation Alarm 1 Type
∇ ∆ change value, ENT enters
NXT goes to 8H2B from NONE or
to next step otherwise.
PRV goes to 8H2E
DEVALM 1 TYPE NONE NONE,
HIGHHIGH (>=), HIGH (>=),
LO (<=), LOW LOW (<=).
8H2A1 Deviation Alarm 1 Trip Value DEVALM 1 TRIP VAL 0.000 Value where deviation will cause
alarm to trip.
8H2A2 Deviation Alarm 1 Hysteresis DEVALM 1 HYSTRSIS 2.000 Absolute offset to clear alarm.
8H2A3 Deviation Alarm 1 Priority DEVALM 1 PRIORITY 1 0 to 255. 0 = suppress unack.
8H2A4 Deviation Alarm 1 Digital Output DEVALM 1 DIG OUT NONE NONE, 1- through 11-
8H1B Deviation Alarm 2 Type
Same as Alarm 1
DEVALM 2 TYPE NONE NONE, HIGHHIGH, HIGH, LOW,
LOW LOW
8H1C Deviation Alarms (Exit)
∆ moves up to Step 8H2
NXT, PRV change step
ALARMS
8H3 Output Alarms OUTPUT ALARMS
8H2A Output Alarm 1 Type
∇ ∆ change value on line 6
ENT enters value.
NXT goes to 8H2B from NONE or
to next step otherwise.
PRV goes to 8H2E
OUTALM 1 TYPE NONE NONE,
HIGHHIGH (>=), HIGH (>=),
LO (<=), LOW LOW (<=).
8H2A1 Output Alarm 1 Trip Value OUTALM 1 TRIP VAL 0.000 Value where output will cause
alarm to trip.
8H2A2 Output Alarm 1 Hysteresis OUTALM 1 HYSTRSIS 2.000 Absolute offset to clear alarm.
8H2A3 Output Alarm 1 Priority OUTALM 1 PRIORITY 1 0 to 255. 0 = suppress unack.
8H2A4 Output Alarm 1 Digital Output OUTALM 1 DIG OUT NONE NONE, 1- through 11-
8H1B Output Alarm 2 Type
Same as Alarm 1
OUTALM 2 TYPE NONE NONE, HIGHHIGH, HIGH, LOW,
LOW LOW
8H1C Output Alarms (Exit)
∆ moves up to Step 8H3
NXT, PRV change step
ALARMS
8H4 Alarms (Exit)
∆ moves up to Step 8H
NXT, PRV change step
COMPOUND
8I Compound List (Exit)
∆ moves up to Step 6B2
NXT, PRV go to steps 8A, 8H.
COMPOUND LIST
