Page 76
Gamatronic Electronic Industries Ltd.
POWER+ RM
50
K
VA, N.Am. Std. – User Guide, Release 1.9
60
3.
Use the arrow keys to set the IP address, and then press Ent:
[Main Menu > SETUP > (password) > Ent > Service > SC2012 > Network > Set IP ADDRESS]
Set IP ADDRESS
157.211.000.252
Figure 67: IP Address
4.
Use the arrows keys to set the gateway and press Ent:
[Main Menu > SETUP > (password) > Ent > Service > SC2012 > Network > Set GATEWAY]
Set GATEWAY
157.211.000.251
Figure 68: Gateway
5. Select
Store:
[Main Menu > SETUP > (password) > Ent > Service > SC2012 > Network]
1> Set IP ADDRESS 157.211.000.253
2> Set GATEWAY 157.211.000.251
3> Set MASK 255.255.255.000
4> Store 5> SNMP factor Select:1
Figure 69: Network menu
Entered information is now stored in the controller.
