Introduction function and components
Create
d
by EBCCW
0
0
:06
25 5112204
The fieldbus cable is connected by fast connectors as mentioned above,
see electrical documentation. If the module contains several communica-
tion interfaces, such as the advanced versions with field distributor, there
is still only one connection point for fieldbus.
Outside and below the electrical cabinet is the connection point for equipo-
tential bonding, see electrical documentation.
. .
Warning: The voltage is 400 V AC (or 480 V AC).
Warning: The voltage in the field distributor is 400 V. There is risk
for serious injury due to electrocution. Immediately seek the care
of a physician if an accident occurs. After the main switch of field
distributor is turned off, voltage is still high in the field distributor.
Warning: Check that the electrical cabinet is closed and locked
after working in the electrical cabinet.
Warning: Never bypass the safety system.
