Technical specification
Create
d
by EBCCW
0
0
:06
15 5112204
2 Technical specification
Complete turn-key version.
In feed and discharge protections are not included.
ESD version elevators are available.
Cabinet for Profibus, Profisafe or Device Net communication for Line con-
trol.
*) Maximum product weights are as follows:
Cycle time 13- 16 sec (low elevator)
18- 24 sec (high elevator)
Max weight* *
Max product height 400 mm
A number of pallets can be elevated at the same time.
Conveyor length Max. length 550/640 mm
Conveyor speed 15 m/min
Electrical environment 50 Hz: 400 V AC
60 Hz: 480 V AC
Type Max. load/level Max. total load in elevator
X85/XK/XT 30 Kg 30 Kg
RTI 15 Kg 100 Kg
DAS 80 85 Kg 85 Kg
Dimensions LxBxH: See appendix.
Weight Low elevator: ~ 300 kg (Depending of configuration)
Weight High elevator: ~ 400 kg (Depending of configuration)
Electrical
specifications Supply: 3 phase + neutral + PE, 400 V AC, 50 Hz, 24 V DC
Max. power: 1 kW N/A
Pneumatic
system N/A
Capacity Products per minute: See application.
Max. speed: See application.
