4. Interconnection

83

031-132-B0-001 Rev. A

TM

©2000

4.3

Connectors, continued

4.3.17 ECM - Alarm Interface & Communications

The Alarm output interface and communications connectors are referenced

and described in Section 3.4, Transponder Interconnection, of the ECM

Operators manual (Alpha p/n 744-862-C0). See Fig. 4-9 items 1 and 9 for

location.

See Fig. 4-9, item 1 for location.

See Fig. 4-9, item 9 for location.

QvÃ

QvÃ

Fig.4-18 RS-485 Communications Input Connector

Fig.4-19 Transponder Interface Connector
