Preface

5

031-132-B0-001 Rev. A

TM

©2000

5.0kW

Auxiliary Power Unit

TM

Table of Contents

Section 3, Maintenence, continued

3.8 Replacing Engine Control Module ........................................................... 47

3.9 Replacing Flexible Gas Hose .................................................................. 48

3.10 Fuel Conversion - Natural Gas to Liquid Propane ...................................... 49

3.10.1 Pre-regulator/Low Fuel Pressure Switch Replacement ..................... 49

3.10.2 Dual-Fuel Load Block Conversion ................................................. 50

3.11 Fan Replacement Procedure .................................................................. 52

3.12 Muffler Replacement Procedure ............................................................. 53

3.13 Muffler Exhaust Flange Gasket Replacement Procedure ............................. 55

3.14 Gas Solenoid Replacement Procedure ..................................................... 56

3.15 Replacing Cabinet Exhaust Duct Upper Seal ............................................ 57

3.16 Removal and Replacement of Generator Set ............................................ 58

3.17 Maxitrol Pre-Regulator Calibration .......................................................... 61

Section 4, Interconnection

4.1 Alarm Sensor States ........................................................................... 65

4.2 ECM Interface Topology and Connectors ................................................. 66

4.3 Connectors

........................................................................... 67

4.3.1

Gas Hazard Alarm Interface ........................................................ 67

4.3.2

Low Fuel Pressure Interface Connector ......................................... 68

4.3.3

Solenoid

........................................................................... 69

4.3.4

Charger Module – Control Interface Connector ............................... 70

4.3.5

Charger Module - Output Interface Connector ................................ 71

4.3.6

APU Ignition Battery Interface Connector ...................................... 72

4.3.7

Alarm Control Interface to APU Interface Connector (APU-I/O)......... 73

4.3.8

ECM PWR-GRI Interface .............................................................. 74

4.3.9

ECM-PWR GRI Enclosure Sensor Interface Ribbon Cable .................. 75

4.3.10 ECM and PWR-GRI Interface Ribbon Cable..................................... 76

4.3.11 Analog and Logic Power Interface Ribbon Cable ............................. 77

4.3.12 ECM - Enclosure Alarm Interface .................................................. 78

4.3.13 Inverter Battery DC Sense Interface Connector .............................. 79

4.3.14 Battery Charger Control Interface Connector ................................. 80

4.3.15 ECM - APU Control Interface ........................................................ 81

4.3.16 ECM - AC Sense 120/240V Interface............................................. 82

4.3.17 ECM - Alarm Interface & Communications ..................................... 83
