1. System Overview
20
031-132-B0-001 Rev. A
TM
©2000
1.5
Generator Modes of Operation, continued
1.5.4. Normal APU Shutdown
The ECM will initiate a normal APU shutdown when AC line is qualified, DC
bus alarm is not active, the 12 minute cool-down period has elapsed, and the
Engine Run command is not active. Otherwise, the ECM will continue to run the
APU until the above conditions are met or a major alarm occurs. Also, the APU
will run for a minimum of 30 minutes if started due to low DC Bus voltage.
1.5.5. Abnormal APU Shutdown
The ECM will immediately shutdown the APU under the following conditions:
Major alarm
Activation of manual engine stop switch
Receipt of software engine stop command
General generator failure
&UDQN &\FOH
8 hx
6r
!
"
#
$
%
&
'
(
8 hxvt
@tvr
$Ãrp $Ãrp $Ãrp $Ãrp $Ãrp $Ãrp $Ãrp $Ãrp
$Ãrp
Qhr
Ãp hx
"Ãrp "Ãrp %Ãrp "Ãrp "Ãrp %Ãrp "Ãrp "Ãrp
@tvr
Pr p hx
6yh
Table 1-1 Normal Mode Crank Cycle
