1. System Overview

22

031-132-B0-001 Rev. A

TM

©2000

1.6

Operator’s Interface Overview

Refer to Figure 1-8 on the following page:

The three positions of the rocker switch are RUN - AUTO - STOP (RAS).

The RAS switch is normally left in the center, AUTO, position so that the ECM

has control of the generator set. A minor alarm is indicated when the RAS

switch is not in the AUTO position. The STOP ("down") position is used to stop

or prevent APU operation during maintenance. Placing the RAS switch to the

STOP position for three (3) seconds, then switching back to AUTO will

clear any latched alarms and start the generator if the cause of the

alarm has been corrected. Placing the RAS switch in the RUN ("up") position

will cause the engine to start and run until this switch is released to AUTO. The

engine may not shut down immediately when the switch is returned to AUTO

from RUN, because the ECM’s shutdown criteria must be met in order to

shutdown the engine. Also, each time the RAS switch is placed in the AUTO

position (from the STOP position), the ECM will start and run the APU for one

minute after a short delay.

The service reset push-button switch has two purposes. It resets the

engine service timer when depressed for 5 seconds and can be used to

determine which alarms are active (see "ECM Alarm Overview" section 1.7).

The service interval is a programmable counter within the ECM that defaults to

100 hours. When 100 hours of engine run time elapses, the Service Required

notification is set and the notification LED illuminates. After the engine has

been serviced, pressing and holding the service reset switch for 5 seconds will

reset the 100-hour service counter. All of the LEDs flash, while the switch is

depressed, until a five-second timer elapses at which time all of the LEDs

remain on solid until the switch is released. This provides feedback to the

technician, indicating the effective resetting of the engine service counter.
