6 Page 6-8 TS-TPI DATA AND REPORTS
TS-TPI Installation and Wiring Guide
How to print the report:
Description of Steps:
Here is the Tank Sentinel display in RUN
MODE, showing SYSTEM, TANK,
SENSOR, etc. are all OKAY...
1) Press the REPORT key to display the
SELECT REPORT GROUP menu...
2) Press the DOWN key twice to show
the PUMP menu selection...
Here is the SELECT REPORT GROUP
menu showing the PUMP menu selec-
tion...
3) Press the M1 key to display the PUMP
STATUS REPORT selection menu...
Here is the PUMP STATUS REPORT
display, showing two choices - PRINTER
or FAX ...
4) Print the report to the console printer
or a fax-modem with the programmed
fax telephone number.
(See the Tank Sentinel Setup Program-
ming Guide 000-1053, for instructions on
how to enter a fax-modem telephone
number into the programming.)
The Tank Sentinel display returns to the
RUN MODE.
SELECT REPORT GROUP (MORE)
PUMP
M1 M2 M3 M4
K W
DOWN
SPACE
SYSTEM TANK SENSOR LINE
OKAY OKAY OLAY OKAY
J W
REPORT
9
PUMP STATUS REPORT
PRINTER FAX
M1 M2 M3 M4
