TS-TPI SETUP PROGRAMMING Page 4-1 4
TS-TPI Installation and Wiring Guide
TPI ENABLE (UP/DOWN)
YES
TPI ENABLE (UP/DOWN)
NO
TPI
ENABLE
SETUP MENU (MORE)
TPI
4 TS-TPI SETUP PROGRAMMING
Prior to Enabling TPI, the System configuration for
Number of Tanks is required. Refer to the Tank
Sentinel Setup Programming Guide.
TPI ENABLE (user entry)
Description of Steps:
Here are the SELECT MENU OPTION menu
names displayed.
1) Press the M1 key to display the SETUP menu.
Here is the main SETUP MENU display
2) Press the DOWN key several times until the TPI
menu name is displayed.
“TPI” may be aligned with any of the menu keys
(M1--M4), depending on what other features are
programmed on enabled. for this example TPI is
aligned with M1
3) Press the M1 key to display the TPI menu
Here is the TPI ENABLE menu.
4) Press the M1 key to display the TPI ENABLE
user entry field. The default selction is NO. Choose
YES to enable TPI programming and subsequent
menus.
5) Use the UP/DOWN keys to change the selection
to YES.
6) Press the ENTER key to accept the entry.
The display returns to the TPI menu, which now
shows the Pump and GROUP menus.
TS-TPI Menu
NOTE
½ Press this key and follow the
highlighted sequence below...
H U
MENU
7
SELECT MENU OPTION
SETUP UPGRADE LANGUAGE DATALOG
M1 M2 M3 M4
M1 M2 M3 M4
M1 M2 M3 M4
TPI
ENABLE PUMP GROUP
