TPI AND LINE LEAK TESTING Page 5-1 5
TS-TPI Installation and Wiring Guide
5 TPI AND LINE LEAK TESTING
Disregard this Chapter if the LN TESTS menu
does not appear. Note that the position of this
menu can be displaced by other menus.
The LN TESTS and LINES menu, only appear if
one or more NO. LINES are entered under the
SYSTEM setup menu.
The TS-LS300 AutoLearn Line Leak Detector
automaticly performs a monthly precision (0.2
gph) test after a 3 hour quiet time.
With this menu you may control the time this
happens or schedule it to happen at a different
time or day than tank leak tests run (to avoid
affecting tank leak test results).
Character input / editing:
• Push UP/DOWN ▲ ▼ keys to show more
menus or menu selections.
• Use menu keys ( M1 to M4 ) to access
menus.
• Press ENTER to accept a selection or input
a value into the setup configuration
memory.
• Press CANCEL to cancel data entry
• Press M1 to move the cursor left Х Х Х Х Х
• Use M2 to move the cursor right Ц Ц Ц Ц Ц
• Press M4 to backspace (delete) one
character to the left Х Х Х Х Х
H U
MENU ½ Press this key and follow the
7
highlighted sequence below
NOTE
SELECT MENU OPTION
SETUP UPGRADE LANGUAGE DATALOG
M1 M2 M3 M4
SYSTEM INFO (MORE)
NO. LINES NO. SENS LIMITS SENTINEL
SETUP MENU (MORE)
EXIT SYSTEM TANKS LINES
SETUP MENU (MORE)
LK TESTS SCLD TEST LN TESTS CLK/CAL
M1 M2 M3 M4
LINE TESTS
SCHEDULE FAIL OG FAULT OG
M1 M2 M3 M4
LN (Line) Test Menu
The TS-LS300 will run the Gross , Monthly and Annual line leak tests
automaticly. Scheduling tests is not required. See the TS-LS300 User Guide
for details of the different Line Leak Tests performed. NOTE
