TS-TPI SETUP PROGRAMMING Page 4-5 4
TS-TPI Installation and Wiring Guide
TYPE “READ ONLY”
Description of Steps:
1) Press the M2 key to display the TYPE PUMP
N “READ ONLY” field...
In this example, the type “VFC” is displayed...
There are five types of controller displays VFC,
SC, SCIII, SCI and VFCIV. The displayed TYPE
PUMP coresponds with the following FE Petro
controllers:
SC STP-SC
SCI STP-SCI
SCIII STP-SCIII
VFC IST-VFC
VFCIV MagVFC
2) Press the CANCEL key to return to the
PUMP N menu.
GROUP “Read Only”
Description of Steps:
1) Press the M3 key to diplay the GROUP
PUMP N “READ ONLY” field...
In this example, the group “2” is displayed...
2) Press the CANCEL key to return to the
PUMP N menu.
TYPE PUMP N READ ONLY
VFC
PUMP N (MORE)
NAME TYPE GROUP ADDRESS
M1 M2 M3 M4
PUMP N (MORE)
NAME TYPE GROUP ADDRESS
M1 M2 M3 M4
CANCEL
GROUP PUMP 1 READ ONLY
2
This menu item defines which pump is connected to which TS-TPI port number. A group
number of 1, 2, 3, or 4 will indicate that the pump is on that port number. The TS-LS300
occupies Group 1 in the factory installed TS-TPI/TS-LS300, therefore the first pump group is
Group 2 and is connected on PORT 2. The Stand Alone TS-TPI has all ports and therefore all
groups available to TPCs.
