Franklin Fueling Systems TS-TPI User Manual
Page 38
TS-TPI DATA AND REPORTS
Page
6-7
6
TS-TPI Installation and Wiring Guide
Pump Controller Status Report
A Pump Status report indicates the current state of the pumps. This report is designed to facilitate
troubleshooting at the site. This is the same information as found in the pump section of the program-
ming and the DISPLAY pump status real time interface. The information can be polled and stored in
System Sentinel or printed at the site by a technician when required.
The following is a representation of a new pump controller status report. Only values available for a
specific controller would be printed.
INCON
INTELLIGENT CONTROLS
INC
P.O. BOX 638
SACO ME 04072
1-800-984-6266
06/12/2002
6:45 PM
PUMP CONTROLLER STATUS
PUMP 1
REGULAR 1
TYPE
SCI
GROUP
1
GROUP TYPE
MAST SLAV
STATUS
61
FAULT
00
VOLTS1
204
CVOLTS1
201
AMPS1
0.1
CAMPS1
6.5
:
:
:
:
SOFTWARE VERSION
3.XXX
