TS-TPI SETUP PROGRAMMING Page 4-7 4
TS-TPI Installation and Wiring Guide
3) Press the ENTER key to accept data entry.
The display returns to the PUMP N menu. Repeat
the user entry steps for each pump.
HEIGHT (user entry)
1) Press the M2 key to display the HEIGHT PUMP
N user entry field...
The default HEIGHT of “+7.0”(inches) is dis-
played...
2) Press the M4 key to backspace and erase the
“+7.000000” default height number.
NOTE: HEIGHT is the distance (in inches or
millimeters) between the bottom of the pump to
the bottom of the TANK. this allows the pump
height to be set by the user, which affects the
handling of the DRY TANK, BLOCKED INTAKE,
and PUMP IN WATER alarms. This variable
defaults to 7 inches and is user-programmable.
3) Use the keypad to enter the height value.
4) Press the ENTER key to accept data entry.
The display returns to the PUMP N menu showing
TANK and HEIGHT.
To repeat these steps for the next pump:
Press the CANCEL key to display the TPI PUMP
menu, which displays AUTO CFG, PUMP 1,
PUMP2, ...
Repeat each PUMP N Menu step for every pump
number.
When these entries are completed...
Press the CANCEL key to display the main TPI
menu, which displays ENABLE, PUMP and
GROUP.
HEIGHT PUMP 1 NUMERIC
+7.000000 BACKSPACE
PUMP N (MORE)
TANK HEIGHT
M1 M2 M3 M4
ENTER
PUMP N (MORE)
TANK HEIGHT
M1 M2 M3 M4
