Franklin Fueling Systems TS-TPI User Manual
Page 14
2
Page
2-8
Installation and Wiring
TS-TPI Installation and Wiring Guide
TPI Configuration Switch
Figure 2-7
Locate the single dip switch on the TS-TPI board labeled SW1.
This set of switches sets how the various ports communicate. The host (ATG) and Pump
Controllers all communicate using RS-485 connections. The TS-LS300 communicates using RS-
232.
The Factory default setting is switches 1, 2 and 3 are OFF and switch 4 is ON. When a second TS-
LS300 is used (more than 4 pipelines at a site) switch 3 is set to the ON positon, see Figure 2-7
SW1 Stand Alone TS-TPI TS-TPI in TS-LS300 Tw o TS-LS300 in us e
1 OFF
OFF
OFF
2 OFF
OFF
OFF
3 OFF
OFF
ON
4 ON
ON
ON
