• Easy to read 5.7” 1/4 VGA TFT color touch screen display with LED backlight
• GUI built in help menus - no external device (e.g. laptop) required for setup, programming, or data retrieval
• Simple expandability for additional analog channels, digital ports, RS-232 ports, and pressure sensors using
plug-in option modules
• Low power usage
• LINUX operating system
• 32-bit, 192-MHz, Arm-9 processor
• 1 Gigabyte internal data logging memory (expandable to 4Gigabytes)
• 10/100Mbit/s Ethernet port for remote programming and data retrieval
• MM/SD Card slot for simple data retrieval or firmware upgrading
• Two (2) USB Host ports for fast and simple data retrieval or firmware upgrading
• USB Device port to allow the System 5000 ™ to appear as a mass storage device
• Two (2) RS-232 serial ports with variable baud rates up to 115.2 Kbps
• Built in speaker with digital audio
• View Status/Push-to-read button (view data without opening the cover)
• Temperature compensated real time clock with lithium backup battery
• Plug-in terminal strip connectors
• Fiberglass enclosure with lexan window
• Operates over a wide temperature range: - 40EF to +140EF (- 40EC to +60EC)
• Quick data retrieval via SD, USB (12Mbit/s) or Ethernet (10/100Mbit/s)
• Four general purpose analog input channels
• Four digital I/O ports
• Switch closure event counters
• AC frequency counter allows direct input for wind speed sensors, etc
• Designed to output a 4-20 mA signal (No external module required)
• SDI-12 Master mode
• Common interface support for 100, 300, and 1200 Baud GOES Transmitters
• Multi-tasking design (ability to configure system while measurements occur)
• Programmable, independent scan rates, offsets, start times, stop times and output conditions fully supported
• Time and event-driven (via digital ports) operations
• Ability to record to multiple non-volatile data/log files
• Support for basic to complex math operations for non-linear sensors
• Built-in BASIC language interpreter integrates user-created Basic 5000 programs for custom/advanced
operations
• MODBUS Master and Slave support (RTU, ASCII, and TCP)
Introduction
5
The System 5000 ™ is the next generation data logger / data collection platform (DCP) using a
touch screen interface for standard and advanced data logging applications. Optional plug-in
modules allow the data logger to be configured for a wide variety of monitoring, data logging,
and SCADA applications. Current option modules include:
• Analog/Digital expansion module
Multiple configurations are available using additional expansion cards and an internal GOES
transmitter. Specifications for System 5000
™
and all option modules are available in the Appendices.
Features
