131
Appendix
Base unit
Display
Type: 5.7", 1/4 VGA (320 x 240 pixels), TFT, color
LED back light, with touch screen
User Interface: Graphical, with built in help menus.
Graphical user interface also accessible remotely
via Ethernet, Serial or USB ports.
Speaker: Internal, for touchscreen key click and user interface
Push-to-read: Pushbutton allows viewing measurement data without
opening the cover.
real Time Clock
Accuracy: 3.5ppm from -40° to +85°C
Battery:
Replaceable lithium cell
General
Processor: 32-bit, 192-MHz, ARM-9
SDRAM: 64-Mbytes
Operating System: LINUX
Data storage
Data Logging: 1Gbyte, expandable to 4Gbytes
Removable: Multi-Media \ Secure Digital (SD) Card,
(32Mbyte to 4Gbyte cards available)
Format: Microsoft™ FAT file system
Interface
USB Host: Two (2) ports, full-speed (works with a thumb drive)
USB Device: One port, full-speed (appears as a mass storage
device)
Ethernet: RJ-45 10/100Base-T, IEEE 802.3
RS-232:
Two (2) ports, 115.2Kbps, DB9, DTE, auto wake up
SDI-12: Two (2) ea, 3-pin connectors, 1200 baud
(Master mode)
+5V excitation Output
Type: Switched, programmable “warmup” time
Voltage: 5.00V, ratio metric with A/D
Accuracy: ± 1.0 mV over load and temperature range
Current:
10mA max load
switched +12 Output
Voltage: Depends on battery voltage
Current: 1A max, protected with polyfuse
4-20 ma Output
Type: 2-wire, loop powered, optically isolated
Resolution: 16-bits
Loop Voltage:
5.5V min, 35V max
Digital I/O
Channels: Four (4) channels, independently configured for input
or output.
Internal 47K pullup resistor to 5.0V
Voltage: 0-5V (input & output)
Input Type: Schmitt, hysteresis: 0.7V min, 1.1V max
Input Voltage Positive going: 2.6V min, 3.3V max
Negative going: 1.8V min, 1.1V max
Output Voltage:
Low: 0.5V max @ 24mA
High: 3.8V min @ -24mA
event, Frequency, Quadrataure Input
Type: 4-inputs, switch closure or voltage pulse
Programmable rising or falling edge triggered
Minimum Pulse Width: 5 mS (event & quadrature)
Input Frequency: 16 KHz max
Counter resolution: 32-bit
Quadrataure Output
Type: Synthesized quadrature encoder, 2-encoders
Outputs: 2-wire/encoder, 0-5V, 64Hz step rate
aC Frequency Input
Type: mV wind speed, dedicated input
Input Range: 1 to 10 KHz at ± 75mVolts or greater 1 to
15 KHz at ± 1 Volt or greater
Input Amplitude: ± 5.0 V Max
Accuracy: ± 0.1%
Resolution:
1/10000 * Reading
analog Input
Channels: Four (4) single ended or two (2) differential
(each channel programable)
Resolution: 24-bit
Accuracy: ±0.05% FS
Input Range:
0 to 5 Volts (has built in transient protection)
GOes radio
Works with external H-2221 GOES transmitter via RS-232 port or H5000+
with built in H-2221 transmitter (see H-2221 specification for details).
Power
Input Voltage: 10.0 to 16.0 volts DC
Input Current:
Sleep: 6mA typical
Active: 80 mA typ (measuring, display off)
Active: 230 mA typ (measuring, display on)
Auto display shut-off after 3 minutes
mechanical
Enclosure: Corrosion resistant fiberglass with clear Lexan®
window
Size:
9.0 in. wide x 10.5 in. long x 6.3 in. deep
Weight: 5.75 lbs (no option cards)
Mounting: Hardware supplied for wall mounting
Expansion Slots: 3 slots
Connectors: Plug-in terminal strips (included)
environment
Operating Range: -40° to +60° C
Storage Temperature:
-60° to +80° C
Humidity: 0-95% non-condensing
warranty
The WATERLOG® H-5000™ is warranted against defects in materials
and workmanship for one year from date of shipment.
note
Specifications subject to change without prior notice due to
ongoing commitment to product testing and improvement.
Last Update Nov 30, 2010
Appendix A: Specifications
