99
General Setup
Buttons/Connections Enabled Without Login
Two external options can be made available without entering a Username/Password if Enabled
by this section.
View Status
The View Status button on the front panel, when pressed, provides a quick view of the current
Tasks on the system as well as their last measurement times and values. New measurements
for Tasks can also be requested from this page using only the View Status button. This screen
is enabled by default even with the Password Protection active. This allows current Tasks
and values, as well as new measurements, to be seen by any who access the 5000, while
modifications to the system configuration are not available. Access to the View Status screen
can be disabled by selecting the Disabled radio button.
USB-B
The USB Device port (labeled as USB-B) on the System 5000
™
, when connected to a computer,
allows the data and log files existing on the system to be retrieved. A prompt on the display
asks whether the system should be mounted as an external drive on the connected computer
and requires the screen to be pressed to do so. This option is enabled by default but can be
disabled by selecting the Disabled radio button.
System Information
The System Information screen provides
access to general information regarding
the System 5000
™
hardware and software.
Firmware versions and revisions, system
reboots, connected expansion cards, and
other information is included. Much of
the information can be beneficial when
troubleshooting. For example, the last
reboots of the system can be helpful in
determining if proper power is being
supplied, or if other potential problems
may be occurring within the system.
The Save Info function button allows the
information displayed within the window
to be saved as text file on the internal memory. This information will be useful when contacting
support for help with troubleshooting any unexpected issues occurring with the System 5000
™
.
