EVS Multicam Version 10.03 – Operating Manual
EVS Broadcast Equipment SA – July 2010
Issue
10.03.C
179
18.3 CONTROLLING THE HYPERMOTION
CAMERA FROM THE REMOTE
18.3.1 D
EFINING THE
N
UMBER OF
M
EMORY
B
LOCKS
I
NTRODUCTION
Some cameras allow the users to split the memory into several blocks. Before
recording material on the hypermotion camera, you need to specify how many
memory blocks you want to use (1, 2, 3 or 4 blocks). By default, only one memory
block is defined.
When using more than one memory block, the blocks are considered as individual
units. In other words you have to manually shift from one block to the other to
continue recording on the next block. Cue points are pre-rolls can only be used on
a single-block memory.
H
OW TO
D
EFINE THE
N
UMBER OF
M
EMORY
B
LOCKS
To define more than one memory blocks on the hypermotion camera, proceed as
follows:
1. In the Hypermotion menu, press MENU to open the secondary menu.
2. Press A to activate the # Blocks field, which allows you to specify in how
many memory blocks you want to split the camera memory.
3. Jog to select the requested number of blocks.
4. Press MENU again to validate your choice and come back to the
Hypermotion main menu.
The camera memory has been split into the requested number of blocks having the
same size. The CAM keys from A to D correspond respectively to the memory
blocks from 1 to 4. only.
