16.1.4 O
VERVIEW ON THE
O
FFSIDE
L
INE
C
OMMANDS
Main Menu
When you access the offside line menu, this is as follows and the Mark key is
blinking:
TRANSP OSD QUIT
SHIFT SIDE REDO UNDO
The following table summarizes the various commands available:
OSD Command Meaning
SHIFT/TILT (A) Moves the line horizontally (Shift) or around its pivot point
(tilt)
SIDE (B) Changes the shaded area from side
REDO (C) Redoes the last undone action.
You can redo the last 10 undone actions.
UNDO (D) Undoes the last action.
You can undo the last 10 actions.
TRANSP (SHIFT+B) Allows the user to change the transparency level with the
jog or lever. Press Enter to validate the action.
OSD (SHIFT+C) Allows the user to hide or display again the information on
the OSD.
QUIT (SHIFT+D) Exits the offside line mode.
Secondary Menu
Pressing the MENU key opens a secondary menu that allows you to specify the
following offside line settings:
Setting Description
Pause duration Time (in frames) between the train or clip is paused and the
offside line mark is displayed.
Fade in/out
duration Duration (in frames) of the fading effect on the IN and OUT
points of the offside sequence.
Preroll duration Preroll (in seconds) before the offside sequence
automatically defined as a cue when the sequence is saved.
