The LCD screen of the Remote displays the complete list of available systems on
the network. The list is organized by the order of connection to the network. Up to
4 pages are available to display up to 31 servers.
The PREVIOUS and NEXT keys appear only when some machines are not visible
on the current page.
L
OCAL MODE
The local system is identified with the Local sign after the name of the system.
The Local function (A) gives direct access to the Local mode and is highlighted
when Local mode is activated.
C
LIPS
M
ODE
The Clip function (B) allows the operator to connect to the clip banks of another
LSM connected to the network. In other words, the VGA clip screen and the F_
keys of the Remote show the clips from the selected LSM. If the operator presses
the RECORD key, he goes in LIVE mode on the local record trains.
R
ECORDS
M
ODE
When the operator selects one of the LSM in the network menu, he connects the
record trains to this LSM. This means that the next time he presses the Records
function (C) the active channels will go in LIVE mode (or near LIVE mode for
remote trains
1 ) on the record trains of the selected LSM. The clips remain
connected to the LSM they were connected to.
C
LIPS
+R
ECORDS
M
ODE
The Clip+Rec function (D) allows the operator to both connect to the clips banks
and to the record trains of a remote server. The VGA clip screen and the F_ keys
of the Remote Panel show the clips from the selected server. The next time the
operator presses the RECORD key, the active channels will go in LIVE mode (or
near LIVE mode for remote trains) on the record trains of the selected LSM.
Select the function key corresponding to the remote system, then the LCD display
returns to the normal mode:
PGM1 112B/04 *PRV1* CAM B
AUX Clip
MIX Sw to IN PGMSpd PREF
P.1 B.1 Clips: ALBERT Records: MICHEL
PL 11: <
Msg:
LOCAL SYNC PRV
CAM A CAM B CAM C CAM D
