Figure 27 wireless lan, Table 13 wireless lan setup wizard 2 – ZyXEL Communications 802.11g Wireless ADSL2+ 4-port VoIP IAD P-2602HWNLI User Manual
Page 72
P-2602HWNLI User’s Guide
72
Chapter 3 Internet and Wireless Setup Wizard
Figure 27 Wireless LAN
The following table describes the labels in this screen.
Table 13 Wireless LAN Setup Wizard 2
LABEL
DESCRIPTION
Network
Name(SSID)
Enter a descriptive name (up to 32 printable 7-bit ASCII characters) for the wireless
LAN.
If you change this field on the ZyXEL Device, make sure all wireless stations use the
same SSID in order to access the network.
Channel
Selection
The range of radio frequencies used by IEEE 802.11b/g wireless devices is called a
channel. Select a channel ID that is not already in use by a neighboring device.
Security
Select Manually assign a WPA-PSK key to configure a Pre-Shared Key (WPA-PSK).
Choose this option only if your wireless clients support WPA. See
for more information.
Select Manually assign a WEP key to configure a WEP Key. See
for more information.
Select Disable wireless security to have no wireless LAN security configured and
your network is accessible to any wireless networking device that is within range.
Select Static WEP (User configured) if you have configured the WEP key before.
Back
Click Back to display the previous screen.
Next
Click Next to proceed to the next screen.
Exit
Click Exit to close the wizard screen without saving.
