P-2602HWNLI User’s Guide

150

Chapter 9 Wireless LAN

9.8.2 Application Priority Configuration

To edit a WMM QoS application entry, click the edit icon under Modify. The following screen
displays.

Figure 80 Application Priority Configuration

The following table describes the fields in this screen.

Table 48 Application Priority Configuration

LABEL

DESCRIPTION

Application Priority Configuration

Name

Type a description of the application priority.

Service

The following is a description of the applications you can prioritize with WMM

QoS. Select a service from the drop-down list box.
FTP
File Transfer Program enables fast transfer of files, including large files that

may not be possible by e-mail. FTP uses port number 21.
E-Mail
Electronic mail consists of messages sent through a computer network to

specific groups or individuals. Here are some default ports for e-mail:
POP3 - port 110
IMAP - port 143
SMTP - port 25
HTTP - port 80
WWW
The World Wide Web is an Internet system to distribute graphical, hyper-linked

information, based on Hyper Text Transfer Protocol (HTTP) - a client/server

protocol for the World Wide Web. The Web is not synonymous with the

Internet; rather, it is just one service on the Internet. Other services on the

Internet include Internet Relay Chat and Newsgroups. The Web is accessed

through use of a browser.
User-Defined
User-defined services are user specific services configured using known ports

and applications.

Dest Port

This displays the port the selected service uses. Type a port number in the

field provided if you want to use a different port to the default port.

Priority

Select a priority from the drop-down list box.
