background image

P-2602HWNLI User’s Guide

Chapter 24 Logs

327

For type and code details, see

Table 138 on page 330

.

Table 130 ICMP Logs

LOG MESSAGE

DESCRIPTION

Firewall default policy: ICMP
, ,

ICMP access matched the default policy and was blocked

or forwarded according to the user's setting.

Firewall rule [NOT] match: ICMP
, ,
,

ICMP access matched (or didn’t match) a firewall rule

(denoted by its number) and was blocked or forwarded

according to the rule.

Triangle route packet forwarded:
ICMP

The firewall allowed a triangle route session to pass

through.

Packet without a NAT table entry
blocked: ICMP

The router blocked a packet that didn’t have a

corresponding NAT table entry.

Unsupported/out-of-order ICMP:
ICMP

The firewall does not support this kind of ICMP packets or

the ICMP packets are out of order.

Router reply ICMP packet: ICMP

The router sent an ICMP reply packet to the sender.

Table 131 CDR Logs

LOG MESSAGE

DESCRIPTION

board %d line %d channel %d,
call %d, %s C01 Outgoing Call
dev=%x ch=%x %s

The router received the setup requirements for a call. “call” is

the reference (count) number of the call. “dev” is the device

type (3 is for dial-up, 6 is for PPPoE, 10 is for PPTP).

"channel" or “ch” is the call channel ID.For example,"board 0

line 0 channel 0, call 3, C01 Outgoing Call dev=6 ch=0

"Means the router has dialed to the PPPoE server 3 times.

board %d line %d channel %d,
call %d, %s C02 OutCall
Connected %d %s

The PPPoE, PPTP or dial-up call is connected.

board %d line %d channel %d,
call %d, %s C02 Call
Terminated

The PPPoE, PPTP or dial-up call was disconnected.

Table 132 PPP Logs

LOG MESSAGE

DESCRIPTION

ppp:LCP Starting

The PPP connection’s Link Control Protocol stage has started.

ppp:LCP Opening

The PPP connection’s Link Control Protocol stage is opening.

ppp:CHAP Opening

The PPP connection’s Challenge Handshake Authentication Protocol stage is

opening.

ppp:IPCP Starting The PPP connection’s Internet Protocol Control Protocol stage is starting.

ppp:IPCP Opening

The PPP connection’s Internet Protocol Control Protocol stage is opening.
