Page 50
P-2602HWNLI User’s Guide
50
Chapter 1 Getting To Know the ZyXEL Device
The following table describes your device’s lights.
1.4 Splitters and Microfilters
This section describes how to connect ADSL splitters and microfilters. See your Quick Start
Guide for details on other hardware connections.
Table 4 Lights
LIGHT
COLOR
STATUS
DESCRIPTION
POWER
Green
On
Your device is receiving power and functioning properly.
Blinking
Your device is rebooting and performing a self-test.
Red
On
Your device is not receiving enough power.
None
Off
Your device is not ready or has malfunctioned.
ETHERNET
1,2,3,4
Green
On
Your device has a successful Ethernet connection.
Blinking
The ZyXEL Device is sending/receiving data.
None
Off
The LAN is not connected.
WLAN
Green
On
Your device is ready, but is not sending/receiving data
through the wireless LAN.
Blinking
Your device is sending/receiving data through the wireless
LAN.
None
Off
The wireless LAN is not ready or has failed.
DSL
Green
On
Your device has a DSL connection.
Blinking
Your device is initializing the DSL line.
None
Off
The DSL link is down.
INTERNET
Green
On
Your device has an IP connection but no traffic.
Your device has a WAN IP address (either static or assigned
by a DHCP server), PPP negotiation was successfully
completed (if used) and the DSL connection is up.
Blinking
Your device is sending or receiving IP traffic.
Red
On
Your device attempted to make an IP connection but failed.
Possible causes are no response from a DHCP server, no
PPPoE response, PPPoE authentication failed).
None
Off
Your device does not have an IP connection
PHONE 1, 2
Green
On
A SIP account is registered for the phone port.
Blinking
A telephone connected to the phone port has its receiver off
of the hook or there is an incoming call.
None
Off
The phone port does not have a SIP account registered.
ISDN
PHONE
Green
On
A SIP account is registered for the phone port.
Blinking
A telephone connected to the phone port has its receiver off
of the hook or there is an incoming call.
None
Off
The phone port does not have a SIP account registered.
