7.7 Port Setup
Ethernet port connections can be in half-duplex or full-duplex mode. Full-duplex refers to a
device's ability to send and receive simultaneously, while half-duplex indicates that traffic can
flow in only one direction at a time. The Ethernet port must use the same speed or duplex
mode setting as the peer Ethernet port in order to connect.
Default
Gateway
Enter the IP address of the default outgoing gateway in dotted decimal notation, for
example 192.168.0.254
VID
Enter the VLAN identification number associated with the IP address. This is the VLAN
ID of the CPU and is used for management only. The default is "1". All ports, by default,
are fixed members of this "management VLAN" in order to manage the device from any
port. If a port is not a member of this VLAN, then users on that port cannot access the
device. To access the Switch make sure the port that you are connected to is a
member of Management VLAN.
Apply
Click Apply to save your changes to the Switch’s run-time memory. The Switch loses
these changes if it is turned off or loses power, so use the Save link on the top
navigation panel to save your changes to the non-volatile memory when you are done
configuring.
Cancel
Click Cancel to reset the fields to your previous configuration.
Management
IP
Addresses
Configure the fields to set additional management IP address.
IP Address
Enter the IP address for managing the Switch by the members of the VLAN specified in
the VID field below.
IP Subnet
Mask
Enter the IP subnet mask in dotted decimal notation. For example, 255.255.255.0.
VID
Enter the VLAN identification number.
Default
Gateway
Enter the IP address of the default outgoing gateway in dotted decimal notation, for
example 192.168.1.254
Add
Click Add to save your changes to the Switch’s run-time memory. The Switch loses
these changes if it is turned off or loses power, so use the Save link on the top
navigation panel to save your changes to the non-volatile memory when you are done
configuring.
Cancel
Click Cancel to reset the fields to your previous configuration.
Index
This field displays the index number of an entry.
IP Address
This field displays the management IP address of the Switch.
IP Subnet
Mask
This field displays the subnet mask of the Switch.
VID
This field displays the VLAN identification number of the network.
Default
Gateway
This field displays the default gateway of the Switch.
Delete
Click Delete to remove the selected entry from the summary table.
Cancel Click
Cancel to clear the Delete check boxes.
Table 12 Basic Setting > IP Setup (continued)
LABEL
DESCRIPTION
