Chapter 30 Cluster Management
ES-2108 Series User’s Guide
230
30.2.1.1 Uploading Firmware to a Cluster Member Switch
You can use FTP to upload firmware to a cluster member switch through the cluster manager
switch as shown in the following example.
Figure 142 Example: Uploading Firmware to a Cluster Member Switch
The following table explains some of the FTP parameters.
30.3 Clustering Management Configuration
Click Configuration from the Cluster Management screen to display the next screen. Use
this screen to configure cluster management.
C:\>ftp 192.168.1.1
Connected to 192.168.1.1.
220 FTP version 1.0 ready at Thu Jan 1 00:47:52 1970
User (192.168.1.1:(none)): admin
331 Enter PASS command
Password:
230 Logged in
ftp> ls
200 Port command okay
150 Opening data connection for LIST
--w--w--w- 1 owner group 3209434 Jul 01 12:00 ras
-rw-rw-rw- 1 owner group 393216 Jul 01 12:00 config
--w--w--w- 1 owner group 0 Jul 01 12:00 fw-00-a0-c5-d4-88-bf
-rw-rw-rw- 1 owner group 0 Jul 01 12:00 config-00-a0-c5-d4-88-bf
226 File sent OK
ftp: 463 bytes received in 0.00Seconds 463000.00Kbytes/sec.
ftp> bin
200 Type I OK
ftp> put 350du1.bin fw-00-a0-c5-d4-88-bf
200 Port command okay
150 Opening data connection for STOR fw-00-a0-c5-d4-88-bf
226 File received OK
ftp: 262144 bytes sent in 0.63Seconds 415.44Kbytes/sec.
ftp>
Table 95 FTP Upload to Cluster Member Example
FTP PARAMETER DESCRIPTION
User Enter “admin”.
Password The web configurator password default is 1234.
ls Enter this command to list the name of cluster member switch’s
firmware and configuration file.
350du1.bin This is the name of the firmware file you want to upload to the
cluster member switch.
fw-00-a0-c5-d4-88-bf This is the cluster member switch’s firmware name as seen in the
cluster manager switch.
config-00-a0-c5-d4-88-bf This is the cluster member switch’s configuration file name as seen
in the cluster manager switch.
