Appendix A Product Specifications
ES-2108 Series User’s Guide
253
Firmware Upgrade Download new firmware (when available) from the ZyXEL web site and
use the web configurator, CLI or an FTP/TFTP tool to put it on the
Switch.
Note: Only upload firmware for your specific model!
Configuration Backup &
Restoration Make a copy of the Switch’s configuration and put it back on the Switch
later if you decide you want to revert back to an earl
i er configuration.
Access Control You can specify the service(s) and computer IP address(es) to control
access to the Switch for management.
Cluster Management Cluster management (also known as iStacking) allows you to manage
switches through one switch, called the cluster manager. The switches
must be directly connected and be in the same VLAN group so as to be
able to communicate with one another.
Table 104 Firmware Specifications
FEATURE DESCRIPTION
Table 105 Switching Specifications
Layer 2
Features Bridging 8 K MAC addresses
Static MAC address filtering by source/destination
Broadcast storm control
Static MAC address forwarding
Switching Switching fabric: 5.6 Gbps, non-blocking
Max. Frame size: 1522 bytes
Forwarding frame: IEEE 802.3, IEEE 802.1q, Ethernet II, PPPoE
Prevent the forwarding of corrupted packets
STP IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol
QoS IEEE 802.1p
Four priority queues per port
Port-based egress traffic shaping
Supports IGMP snooping
IGMP snooping for up to 16 VLANs.
VLAN Port-based VLAN setting
Tag-based (IEEE 802.1Q) VLAN
Number of VLAN: 4K, 1000 static maximum
Supports GVRP
Port
Aggregation Supports IEEE 802.3ad; static and dynamic (LACP) port trunking
Two groups (up to four ports each)
Port mirroring All ports support port mirroring
Bandwidth
control Supports rate limiting at 64K increment
Security IEEE 802.1x port-based authentication
Static MAC address filtering
Limiting number of dynamic addresses per port
