Chapter 6 System Status and Port Statistics
ES-2108 Series User’s Guide
68
Figure 31 Status: Port Details (ES-2108-G)
The following table describes the labels in this screen.
Table 8 Status: Port Details
LABEL DESCRIPTION
Port Info
Name This field shows the name of the port.
Link This field shows whether the Ethernet connection is down, and the speed/duplex
mode.
Status If STP (Spanning Tree Protocol) is enabled, this field displays the STP state of the port
(see
Section 11.1.3 on page 103 for more information).
If STP is disabled, this field displays FORWARDING if the link is up, otherwise, it
displays STOP.
PD
PowerConsu
mption (W)
(PWR model
Only) This field is only available on the PWR model but not available for the Gigabit and
mini-GBIC slots.
This field shows the power consumption of the powered device connected to the port.
