NetAtlas Enterprise 1.00 User’s Guide
65 Chapter 5 Status
5.3 VLAN Status
Follow the steps below to view the VLAN status of a switch.
1 Click Status and then VLAN Status.
2 Choose a switch from the list located on the left-hand side of the screen.
Hello Time
(second)
This is the time interval (in seconds) at which the root device transmits a
configuration message. The root bridge determines Hello Time, Max Age and
Forwarding Delay
Max Age (second) This is the maximum time (in seconds) a switch can wait without receiving a
configuration message before attempting to reconfigure.
Forwarding Delay
(second)
This is the time (in seconds) the root switch will wait before changing states (that
is, listening to learning to forwarding).
Cost to Bridge This is the path cost from the root port on this switch to the root switch.
Port ID This is the priority and number of the port on the switch through which this switch
must communicate with the root of the spanning tree.
Topology Changed
Times
This is the number of times the spanning tree has been reconfigured.
Time Since Last
Change
This is the time since the spanning tree was last reconfigured.
Polling The text box displays how often (in seconds) this screen refreshes. You may
change the refresh interval by typing a new number in the text box and then
clicking the Apply button.
Close Click Close to close the screen.
Table 16 Status: STP Status (continued)
LABEL DESCRIPTION
