NetAtlas Enterprise 1.00 User’s Guide
Chapter 1 Introducing the EMS 36
Figure 26 Map Object Properties: General l
Table 2 Map Object Properties: General
FIELD DESCRIPTION
Label Type a device name for identification purposes. If you do not configure this field,
the default label is “New Object”.
Type This field shows what type of device it is, for example a hub, workstation, router
etc. This field displays Device for the switch.
Address Type the IP address of the switch.
Icon You may change the default icon by clicking >> and then choosing a different
icon.
Group This is the group number associated with this type of device. This field is
optional.
Descr Type a description of your device in this (optional) field.
1.7 Using SNMP
Check that you are using SNMPv2c. If you are not using SNMPv2c, you must uninstall any
previous versions and install SNMPv2c. Refer to RFC 1901 for more information on SNMP
Version 2c (SNMPv2c). Follow this procedure to use SNMPv2c.
1 Right-click the Device icon and select Properties.
2 Click the Access tab.
