NetAtlas Enterprise 1.00 User’s Guide
Chapter 4 58
Delete Click on a VLAN in the left-hand column of this screen and then click the Delete
button to remove it from the VLAN template.
Modify Click on a VLAN in the left-hand column of this screen. Change the VLAN Name
or change the configuration of the egress, forbidden and untagged ports. Click
the Modify button to save the changes to the switch.
If you want to change the VLAN ID of a VLAN configuration, you can only delete
the VLAN configuration or create a new VLAN configuration using a different
VLAN ID.
Port List Click on a port in the Egress Ports list to add the selected port to the port list. If
a port is not selected from any of the three port lists, then it is a normal tagged
port.
This fields displays all available ports that are participating in a VLAN. A tagged
port is marked T while an untagged port is marked U.
Close Click Close to close the screen.
Table 12 Template: VLAN (continued)
LABEL DESCRIPTION
